DCF-F Explosion Proof Solenoid Coil

The DCF-F explosion proof solenoid coil is certified flameproof coil specially matched for pulse jet valves. It meets strict international explosion-proof standards, marked Exmb II T4 / DIP A20 TA, T4. With IP65 full waterproof and dustproof grade, it safely works in flammable gas, vapor and combustible dust hazardous zones. Factory tested, fully sealed and ideal for industrial dust collectors in high-risk explosion environments.

Model:DCF-F

Send Inquiry

Product Description

Product Features & Function

The DCF-F explosion proof solenoid coil adopts fully epoxy resin potting sealing structure, with aluminum alloy housing for strong anti-impact and stable performance. It uses an air-electric isolation design, so there is no risk of internal spark leakage. It is safe and reliable for controlling the pulse valve opening and closing. The fuse and temperature protection parts that are already built in stop the device from overloading or the circuit from short-circuiting. It will always stay below 130°C, so there are no hidden safety risks. This coil is the perfect replacement for explosion-proof pulse valves in dangerous workshops. You don't need to replace the whole valve, which saves maintenance costs and downtime.

Product Parameter

Model: DCF-F Explosion Proof Solenoid Coil

Explosion-proof Grade: Exmb II T4, DIP A20 TA, T4

Protection Level: IP65 Waterproof & Dustproof

Housing Material: Aluminum alloy, engineering plastic sealed winding

Max Surface Temperature: ≤130℃

Wire length: 1.5m standard, support customization

Applicable Environment: Zone 1, Zone 2 flammable gas areas, A20 combustible dust areas

Altitude Limit: Below 1000 meters

Ambient Humidity: ≤95% (25℃)

Core Design: Epoxy resin sealed, voltage resistance, arc resistance, moisture proof, high and low temperature resistant

Built-in Parts: Overload protection, short circuit protection, fuse tube, temperature electronic protection

Application: Explosion-proof pulse valve, industrial dust collector, chemical plant, cement plant, power plant hazardous workshops

Voltage	Power	Coil Temperature	Ambient Temperature	Atmospheric Pressure	Air Humidity	Standard / Area	Others
AC 220V	24W	≤ 80°C	-20 ~ +45°C	80 ~ 110 kPa	5% ~ 90% (at +25°C)	Suitable for Class IIA, IIB, IIC explosive gas environments, Zones 1 & 2, and combustible dust Zones 21 & 22 with temperature classes T1–T4	Free from severe vibration and impact
DC 24V	13W
